Place pallet arm into the lower wheel bracket.
Match up number on pallet arm to number on lower wheel bracket. Install nylon lock nut and washer on other side of bolt. Carefully release swing arm until it rests against the hex bolt. Install hex bolt with one washer from the side of swing arm. After installing spring assembly, push swing arm down and hold in place. While spring pack is resting in place, lower swing arm onto top of spring assembly. Place bottom of spring assembly into grooves as shown, then insert the top of the spring pack into the top grooves. Lift up swing arm and locate empty grooves on the bottom of the swing arm. Reference the correct model in the table below for correct quantity of parts. NOTE: Quantity of parts depends on model purchased. IT IS RECOMMENDED THAT YOU ASSEMBLE YOUR PRESS WITH MORE THAN ONE PERSON PARTS FOR ASSEMBLY Please be sure you are using the correct tools and parts to assemble your press. Any parts and tools that are necessary for assembly will be listed on each step. All parts are labeled on page 6 and will be referred to in the following steps.
The Odyssey Series is shipped partially disassembled to prevent damage to the unit during transportation. Use two persons for lifting! SPECIFICATIONS
IMPORTANT: Shipping boxes and equipment are heavy. Be sure the area around the press is free of clutter, spills, or debris. Keep small children and pets out of reach of the press.
Be sure print heads are in their upright position when installing and removing screens. Do not sit, stand, or apply excess weight on press. WORKHORSE PRODUCTS HOW TO
Anybody operating the press should first read through this owner’s manual to ensure a full understanding of how to properly use and maintain the Mach.
